Occupational Health

Hearing

2500 Package

Ideally suited for industrial, occupational health, physicians and clinics that need to meet O.S.H.A. hearing test requirements.

Features
  • AUTOMATIC, SEMIAUTOMATIC, MANUAL TESTS
  • PRINT AND STORE TESTS AUTOMATICALLY
  • INTERNAL MEMORY STORES UP TO 260 TESTS
  • COMPUTER COMPATIBLE
  • LARGE CHARACTER LCD DISPLAY
  • MONITOR TEST CONDITIONS IN PROCESS
  • INPUT SOCIAL SECURITY NUMBER FOR ID
  • LARGE PRINT OUT RESULTS
  • CALIBRATION DATE, TEST DATE, CALIBRATION DUE DATE ON REPORT
  • FAST PRINT (Less than 20 seconds depending on printer)
  • VISUAL AND AUDIBLE ALARMS
  • PAUSE, RESUME FOR OPERATOR CONTROL
Specifications
  • MEETS OR EXCEEDS A.N.S.I. S3.6-1989, O.S.H.A. REQUIREMENTS
  • TEST FREQUENCIES: Accuracy better than 1% AUTOMATIC: 500, 1000, 2000, 3000, 4000, 6000, 8000 (with validity check at 1000 Hz) SEMIAUTOMATIC & MANUAL MODES: 250. 500, 750, 1000, 1500, 2000, 3000, 4000, 6000, 8000 (Hz)
  • TOTAL HARMONIC DISTORTION: Less than 3%, typical 1%
  • HEARING LEVEL RANGE: 0 to 95dB in 5dB increments except at 125Hz to 75dB and 250 and 8000 Hz to 85dB. Accuracy +/- 1dB
  • DATA OUTPUT: RS-232 9600 baud, 8 bits, no parity, DTR for printer/computer ID
  • STORAGE CAPACITY: Up to 260 Audiograms
  • PRINT TIME: Typically less than 20 seconds (printer dependent)
  • EARPHONES: TDH-39, 10 Ohm
  • DISPLAY: .375 high, 2 line by 16 characters, backlight LCD
  • POWER SUPPLY: 107-127 VAC 60 Hz, 10 Watts. UL Approved (optional 220 VAC 50/60 Hz available)
  • CASE: Impact resistant A.B.S. plastic, W 10″ x L 8″ x H 4.2″. Total audiometer weight 4.0 Ibs.
  • WARRANTY: 5 years on base system
Features/Specifications
  • OTO-CHEK
5 Year Limited Warranty

This warranty is extended to the original purchaser of the audiometer by AMBCO through approved Special Instrument Distributor or through AMBCO and covers defects in materials of workmanship for a period of 5 years from the date of delivery to the original purchaser.

Earscan 3 Automatic Threshold Audiometer (ES3)

Whether being carried from location to location or being used at a fixed site, the Earscan® 3 audiometer’s size makes it a perfect fit. This lightweight, truly portable audiometer is equally at home in the palm of your hand or taking up a fraction of the work space of other “portable” audiometers.

The Earscan® 3 has been designed to the same strict quality standards that have defined all Micro Audiometrics products, from the durability of the enclosure to the signal presentation quality. With one of the longest warranties on the market, you can be sure the Earscan® 3 will serve you now and in the years to come.

The standard Earscan® 3 is a fully programmable audiometer, allowing customization of the entire test procedure, from the intensity step size to the frequencies selected for testing and the order in which they are presented. Calibration is password protected to ensure the integrity of data. Built in calibration reminders ensure the validity of test results. Test data transfer and remote audiometer control (USB interface) are available through compatible PC software (software sold separately.)

Booths

Spirometry

Pneumotrac Spirometer with Spirotrac 6 Software

Full featured desktop spirometry complete with Spirotrac software to integrate with your PC, laptop or tablet.

The next generation Pneumotrac™ Spirometer combined with our new and improved Spirotrac® software is a powerful and flexible respiratory diagnostic device. Improved sleek design with no moving parts for optimal robustness. The new Pneumotrac™ has a reduced desktop footprint allowing spirometry testing to take place wherever your PC, laptop or tablet can go.

Suitable for testing both adults and pediatrics due to the extremely reliable Fleisch flow technology which is accurate even at very low flow rates.

Pneumotrac with our redesigned Spirotrac 6 software is compliant with the 2019 ATS/ERS Technical Standards, ensuring your service meets international guidelines on accuracy and reporting. Spirotrac 6 features a brand new intuitive interface with advanced quality control feedback for rapid and easy testing.  Compatible with all major EHR/EMR systems via HL7.

The Pneumotrac Spirometer comes with:

Spirotrac 6 Software (including HL7 connection kit)
Protective carry pouch
USB cable

This device comes with a Free 5-Year Warranty including unlimited technical support when registered within 30-days of purchase.

Vitalograph provides free certified training for all of its respiratory diagnostic solutions.



Be free to help your patients perform Spirometry

The Pneumotrac has an integrated V-Core™ flowhead, allowing you to focus on helping your patients achieve their best spirometry test, confident that you are capturing accurate and reproducible results.

Safely measure lung capacity with this Spirometer’s “No Contact No Risk” design

For over 25 years, Depisteo’s head office has chosen the Fleisch type pneumotachograph in the design of its spirometers for its qualities of reproduction and measurement accuracy. No calibration or disinfection, or cross contamination is required.



EasyOne® Air

Portable & PC spirometer

EasyOne Air is a flexible, accurate and proven spirometry solution designed for healthcare providers large and small. Utilizing TrueFlow™ technology, this portable spirometer delivers reliable results without the need for calibration to ensure lifetime worry-free operation. Thanks to the vivid color touch screen, it is easy to navigate, view real-time results and enter data.

  • Flexible Use, Consistent Results

    EasyOne Air can be used as a portable or as a PC spirometer. It delivers consistent results in various conditions and settings.

  • Calibration-free TrueFlow™ Technology

    Utilizing high-quality components and Swiss precision-engineering, TrueFlow™ delivers robust and reliable testing results without needing calibration.

  • Color Touch Screen

    View real-time graphs, quickly enter patient data and easily navigate with the high resolution color touch screen in the EasyOne Air.

  • Bluetooth and EMR Connectivity

    Easily connect to PC for real-time patient incentives, data exchange and EMR connectivity.

3 Litre Precision Calibration Syringe

Providing assured accuracy for calibration verification and linearity checking.

Vitalograph precision syringes provide quick and easy accuracy checks with reliability and fast verification.

The 3L precision syringe can be used with flow or volume sensor systems and is compatible with any manufacturers’ equipment.  Each syringe has a unique serial number and history file with accuracy certified to better than 0.5%.

For flow measuring spirometers, the ATS/ERS 2019 Technical Standards of Spirometry guidelines recommends daily calibration verification using a 3 litre syringe with a filter attached.

The 3L precision syringe is recommended for all spirometers as required by ISO 26782:2009.  A range of adaptors is available.

This device comes with a Free 5-Year Warranty including unlimited technical support when registered within 30-days of purchase.

Eco BVF Kits (Bacterial Viral Filters) with Nose Clip, Mouthpiece

Kits include Eco BVF™, nose clip and bite on mouthpiece combinations shown below.

Optimal protection for patients, staff and equipment during pulmonary function testing.

Validated cross-contamination efficiency >99.999%.

Traps expectorated matter, bacteria and viruses.

Vision

Screening Tests

  • Acuity with Letters
  • Vertical and Horizontal Phoria
  • Fusion
  • Depth Perception
  • Color
  • Complete Visual Field (Vertical, Horizontal, Nasal, and Central)
  • Amsler Grid
  • Luminosity: High, Low, and Mesopic (Night) Photopic
  • Distances: Far (24 ft.), Intermediate (20 in.), and Near (14 in.)
  • Binocular and Monocular Modes
  • Computerized VT1 Control Included

Unique Features

Choice of Computerized VT1 Control and/or Remote Control
